SPEARS 7080101 Bronze Ball Valve, 1/4 FNPT x MNPT, Inline

Product Description

The SPEARS 7080101 is a manual ball valve made from bronze. This valve has a size of one quarter inch with female NPT and male NPT connections. It features an inline design and a lever handle for operation. Suitable for steam applications, this valve can handle a maximum pressure of 600 psi.

• Material: Bronze body with brass ball
• Temperature range: -20 degrees Fahrenheit to 425 degrees Fahrenheit
• Maximum operating pressure: 600 psi

Product Highlights

This ball valve is built for durability and efficiency in steam systems. The lever handle enables easy manual operation, making it a reliable choice in various applications.

Product Information

Standard Information

• Valve Size: 1/4 inch
• Connection Type: FNPT x MNPT

Technical Specifications

• Body Material: Bronze
• Max. Temperature: 425 degrees Fahrenheit
• Min. Temperature: -20 degrees Fahrenheit
• Max. Operating Pressure: 600 psi
• Handle Type: Lever
• Dimensions: 2.75 inches x 1.25 inches x 1.75 inches
• Weight: 0.63 pounds
• Standards: ASTM B584-C84400, BUILD AMERICA BUY AMERICA ACT (BABA), BUY AMERICAN ACT (BAA)
