Southwire MHF4/0-4/0-2/0-4MR Mobile Home Feeder 500 FT

Product Description

The Southwire MHF4/0-4/0-2/0-4MR mobile home feeder is designed for connecting mobile homes to electrical supply. It is compliant with National Electrical Code standards and suitable for direct burial in earth. This product is ideal for environments where permanent wiring is necessary. The feeder has a maximum conductor temperature of 90 degrees Celsius and a voltage rating of six hundred volts.

• Conductor: Class B compact stranded bare aluminum Alumaflex as per ASTM B800 and ASTM B801
• Ground: Green insulated aluminum
• Neutral: Black with white stripe

Product Highlights

Designed for reliable mobile home electrical connections with sturdy aluminum conductors, this feeder is prepared for direct burial under various conditions.

Product Information

Standard Information

• Conductor Size: 4/0 AWG
• Conductor Number: 2

Technical Specifications

• Conductor Strands: 19
• Diameter Over Conductor: 0.474 inches
• Insulation Thickness: 80 mils
• Ground Size: 1x4
• Approx. OD: 1.552 inches
• Aluminum Weight: 563 lbs/1000'
• Approx. Weight: 795 lbs/1000'
