Southwire LR9M Type Lr Conduit Body 3.5 Inches

Product Description

The SOUTHWIRE LR9M is a 3.5-inch malleable iron rigid threaded Type LR conduit body designed for use in rigid metal conduit systems. This fitting provides a directional change in conduit runs — specifically a left turn with a rear entry — while allowing access for wire pulling, splicing, and inspection. The malleable iron construction delivers durability in demanding environments. Licensed electricians and journeymen install this fitting as part of rigid conduit infrastructure in commercial and industrial electrical systems.

The LR9M is suited for rigid metal conduit installations in commercial and industrial settings where conduit bodies are required to navigate corners or tight routing paths. At 3.5 inches trade size, this fitting serves larger conduit runs typically found in main distribution, service entrance, and branch circuit applications. It is threaded for direct engagement with rigid conduit couplings and fittings.

Key Features

• Malleable iron construction for strength and impact resistance in rigid conduit systems
• Type LR configuration provides a left-turn conduit body with rear entry
• Threaded connections for use with rigid metal conduit
• 3.5-inch trade size for large conduit runs
• Provides access point for wire pulling and conductor inspection

Compatibility

Designed as an OEM-style replacement and standard fitting for 3.5-inch rigid metal conduit systems. Referenced as equivalent to Madison LRM-350.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements for rigid metal conduit systems. De-energize all circuits and verify the absence of voltage before working in the conduit run. Apply appropriate thread sealant or conduit thread compound to threaded connections as required by local code. Ensure the conduit body cover is secured and gasketed where environmental protection is needed.

Technical Specifications

• Trade Size: 3.5 inches
• Material: Malleable Iron
• Conduit Body Type: LR (Left Rear Entry)
• Connection Type: Rigid Threaded
• UPC: 751338214200

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: LR9M
