Southwire LR10M Type Lr Conduit Body 4 Inches

Product Description

The SOUTHWIRE LR10M is a 4-inch malleable iron rigid threaded Type LR conduit body designed for use in electrical conduit systems requiring a left-rear directional pull point. Malleable iron construction provides the mechanical strength needed to withstand jobsite conditions and long-term service in both exposed and concealed installations. The threaded entry design is compatible with rigid metal conduit and intermediate metal conduit fittings. Licensed electricians and electrical contractors install this fitting where conduit runs require a 90-degree change in direction combined with a pull or splice access point.

This conduit body is suited for commercial and industrial electrical installations where rigid threaded conduit systems are specified. It serves as a junction and pull point in raceway systems, allowing conductors to be pulled without excessive bending stress on the wire. The Type LR configuration directs conduit entries from the left side and rear, making it appropriate for tight routing situations along walls, ceilings, or structural members. It is also referenced as a replacement for the Madison LRM-400.

Key Features

• Malleable iron construction for high mechanical durability in demanding environments
• 4-inch trade size accommodates large-diameter rigid or IMC conduit runs
• Type LR body configuration provides left-rear entry for 90-degree directional changes
• Threaded hubs ensure secure, code-compliant conduit connections
• Removable cover plate allows access for wire pulling and conductor splicing

Compatibility

Replaces Madison LRM-400. Designed as an OEM-style replacement fitting for 4-inch rigid metal conduit and intermediate metal conduit threaded systems.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize the circuit and verify zero voltage with a meter before opening any conduit body for wire pulling or splicing. Use appropriate thread sealant or conduit wrench to achieve a secure, weathertight threaded connection. Do not exceed the conduit body fill capacity as defined by NEC Article 314 for the conductors being installed.

Technical Specifications

• Trade Size: 4 inches
• Body Type: Type LR
• Material: Malleable Iron
• Connection Type: Rigid Threaded
• UPC: 751338214309

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: LR10M
