Southwire E-LR-125W 1-1/4 EMT Push Install Type-LR Conduit Body

Product Description

The Southwire E-LR-125W is a Type LR EMT conduit body. It features a hub size of 1-1/4 inches and is made from copper free aluminum. This product is designed for use in EMT conduit systems. It serves as a junction or pull box, allowing for changes in direction.

• No tools are required for installation
• Reusable and tested for up to 100 removal cycles
• Replaces traditional screw and compression couplings

Product Highlights

This conduit body maintains a grounding path and can be reused efficiently.

Product Information

Standard Information

• Brand: Southwire Company
• MPN: E-LR-125W

Technical Specifications

• Type: Type LR
• Hub Size: 1-1/4 inches
• Connection Type: Push-On
• Material: Copper Free Aluminum
• Dimensions: 3.109 inches W x 3.589 inches D x 8.064 inches H
