Southwire Company 47660312 8 Cond. Plenum Rated Wire 250ft Spools

SKU: 47660312
Availability: In Stock

Ships same day if ordered by 12 pm

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$184.28
$184.28
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The SOUTHWIRE COMPANY 47660312 is an 8 Cond. Plenum Rated Wire available in 250ft spools. This thermostat cable features bare copper conductors, low-smoke PVC insulation and a plenum PVC jacket. It is suitable for installation in fabricated ducts, in risers and within buildings in other than air-handling spaces and risers.

  • Bare Copper conductors for excellent conductivity and low voltage drop.
  • Low-Smoke PVC insulation.
  • Plenum PVC jacket.

Product Highlights

This plenum rated thermostat cable is ideal for HVAC equipment and offers efficient jacket stripping and removal with a durable rip cord.

Product Information

Standard Information

  • Brand: SOUTHWIRE COMPANY
  • Manufacturer Part Number: 47660312

Technical Specifications

  • Conductor Size: 18 AWG
  • Conductor Type: Bare Solid Copper
  • Jacket Material: PVC
  • Number of Conductors: 8
  • Series: Genesis
  • Strands: Solid
  • Temperature Rating: -20 to 60 deg C
  • Type: General Purpose
  • Voltage Rating: 150 VAC
  • Shielding: Unshielded
  • Nominal Total Weight (lbs/1000'): 51
  • Nominal Total Weight (kgs/km): 76
  • Outside Diameter: 0.204 in
  • Insulation Thickness: 0.006 in
  • Jacket Thickness: 0.015 in
  • Capacitance: 22.8 pF/ft
  • Impedance: 67 Ohm
  • Insulation Color: Assorted
  • Package Type: Reel
  • Mfg Standards/Approvals: NEC Article 725|UL File No. 13
