Southwire C5SSCG 1-1/2 in Aluminum C Type Conduit Body

Product Description

The SOUTHWIRE C5SSCG is a 1-1/2 inch EMT and rigid metal conduit combination, C-type conduit body supplied with a cover and gasket. Manufactured from naturally corrosion-resistant aluminum, this conduit body features a straight-through configuration that provides the easiest access point for pulling conductors and making splices. Smooth, rounded integral bushings protect conductor insulation at the hubs. The domed cover adds internal volume for wiring, and the included gasket supports a NEMA FB 1 rating for wet location use. Licensed electricians and electrical contractors install this fitting in commercial and industrial conduit runs.

The C5SSCG is suited for use with threaded rigid metal conduit in both indoor and outdoor applications where wet location ratings are required. Its lightweight aluminum construction keeps overall raceway weight down while delivering solid ground continuity. The C-type body is the most common configuration for straight pulls and mid-run access, making it a standard choice on exposed conduit runs in commercial buildings, industrial facilities, and utility installations where periodic conductor access is anticipated.

Key Features

• C-type straight-through configuration for efficient conductor pulling and splicing access
• Naturally corrosion-resistant aluminum construction with excellent ground continuity
• Smooth, rounded integral hub bushings protect conductor insulation during pulls
• Domed cover provides additional wiring volume inside the body
• NEMA FB 1 rated for wet locations
• UL listed

Compatibility

Designed for use with 1-1/2 inch threaded rigid metal conduit. Compatible with standard C-type conduit body cover and gasket hardware. Use with threaded rigid metal conduit only; not rated for direct EMT setscrew or compression fittings at the hubs.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize the circuit and verify absence of voltage before opening any conduit body on an existing run. Covers must be secured and gaskets properly seated to maintain the wet location rating. Do not overtighten hub connections, as aluminum threads can be damaged by excessive torque.

Technical Specifications

• Trade Size: 1-1/2 inches
• Conduit Body Type: C Type
• Compatible Conduit: Threaded Rigid Metal Conduit
• Material: Aluminum
• Wet Location Rating: NEMA FB 1
• Includes: Cover and Gasket
• Listing: UL Listed
• UPC: 751338837904

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: C5SSCG
