Southwire 47190107 thermostat cable, general purpose 150v 18 awg 12c solid 250 ft

SOUTHWIRE
Brand: SOUTHWIRE
SKU: 47190107
Availability: In Stock

Ships same day if ordered by 12 pm

%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
$273.83
$273.83
HAVE A QUESTION?

Our team is ready to help!

  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Product Description

The SOUTHWIRE 47190107 is a general purpose thermostat cable designed for thermostat and HVAC control wiring applications. This 18 AWG 12C solid copper cable is rated for 150 volts and temperatures from -20 °C to 75 °C. It is suitable for installation in metal raceways, solid bottom metal cable trays, and within buildings, including areas exposed to sunlight. Featuring bare copper conductors and a PVC jacket, it ensures reliable signal transmission for heating, ventilation, and air conditioning systems.

  • Installed in a metal raceway that complies with 300.22(B).
  • Bare Copper conductors for excellent conductivity and low voltage drop.
  • Rated for 150 Volts and -20 °C to 75 °C.

Product Highlights

General purpose thermostat cable with 12 solid 18 AWG copper conductors, suitable for HVAC control wiring and sunlight exposure.

Product Information

Standard Information

  • Brand: SOUTHWIRE
  • Manufacturer Part Number: 47190107
  • Country of Origin: United States

Technical Specifications

  • AWG Size: 18 AWG
  • Number of Conductors: 12
  • Stranding: Solid
  • Shielding: Unshielded
  • Nominal Total Weight (lbs/1000ft): 71
  • Nominal Total Weight (kg/km): 106
  • Construction: 18 AWG 12C Solid
  • Outer Jacket Color: Brown
  • Packaging: 250 FT Reel
  • Product Type: Thermostat Wire
  • Cable Type: Non-Plenum
  • Manufacturer: Genesis Cable Systems (Southwire)
  • MPN: 47190107
  • Application: Thermostat and HVAC Control Wiring
  • Condition: New
  • Part Type: Wire & Cable
  • UL Standard: UL 1685 General Purpose Rating, UL 13 Power-Limited Circuit Cables Type CL2
  • Environmental Compliance: Sunlight Resistant, REACH/RoHS Compliant
  • Rated Voltage: 150 Volts
  • Rated Temperature: -20 °C to 75 °C
  • Country of Origin: United States
