Southwire 32175012 Multiconductor Shielded Cable, Plenum 300 Volt 18 AWG 8 Conductor 500 FT

Product Description

The SOUTHWIRE 32175012 Multiconductor Shielded Cable is a plenum-rated cable designed for installation in fabricated ducts, environmental air spaces, and risers. It features bare copper conductors for conductivity, low-smoke PVC insulation, and a foil shield over all conductors. The cable is rated for 300 Volts and operates within a temperature range of -20 °C to 75 °C, making it suitable for various low-voltage applications.

• Bare Copper conductors for excellent conductivity and low voltage drop.
• Low-Smoke PVC insulation and Plenum PVC jacket.
• Foil shield over all conductors for signal integrity.

Product Highlights

Plenum rated for air-handling spaces, featuring a durable rip cord and length markings for easy installation.

Product Information

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 32175012

Technical Specifications

• AWG Size: 18 AWG
• Number of Conductors: 8
• Conductor Stranding: Stranded
• Shielding Type: Shielded
• Nominal Weight (lbs/1000ft): 57
• Nominal Weight (kg/km): 85
• Jacket Color: Natural
• Conductor Color Code: White/Yellow/Orange/Red/Green/Blue/Brown/Black
• Packaging: 500 FT Reel
• NFPA 262 Compliance: Plenum Rated
• CSA C22.2 No. 2556 Compliance: FT6 Rated
• UL 444 Compliance: Communication Cables, Type CMP (22 AWG - 16 AWG)
• UL 1424 Compliance: Cables for Power-Limited Fire-Alarm Circuits, Type FPLP
• UL 13 Compliance: Power-Limited Circuit Cables, Type CL3P
• Environmental Compliance: REACH/RoHS Compliant
• Voltage Rating: 300V
• Temperature Rating: -20°C to 75°C
• Application: Security, Alarm, Fire Alarm, Life Safety Systems
