Southwire 18-4 18/4 Pair Str CU PVC/PVC SPOS TC Instrumentation Cable 300V

SOUTHWIRE
Brand: SOUTHWIRE
SKU: 18-4
Availability: In Stock

Ships via freight in 1-3 business days
$133.64
$133.64
LTL Delivery

This product weighs 133 lb each and will be shipped via LTL carrier. A lift gate option will be added free of charge for your convenience.

HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The SOUTHWIRE 18-4 Instrumentation Cable is a Type PLTC per UL 13 and Type ITC per UL 2250 cable, designed for process control, instrumentation, and control circuits. This 18 AWG cable features 4 conductors, constructed with 7-strand copper conductors insulated with PVC. It is suitable for use in cable trays, raceways, and conduit, and is rated for -30°C to 105°C operating temperatures. The cable is also sun resistant and rated for Class I Div II hazardous locations.

  • Designed for process control, instrumentation, and control circuits as per NEC Article 336.
  • Constructed with 7-strand copper conductors insulated with PVC.
  • Rated for -30°C to 105°C and Class I Div II hazardous locations.

Product Highlights

This instrumentation cable features 18 AWG 4-conductor construction with PVC insulation, dual aluminum polyester foil shielding, and a durable black PVC jacket, ensuring reliable performance in demanding industrial environments.

Product Information

Standard Information

  • Brand: SOUTHWIRE
  • Manufacturer Part Number: 18-4
Technical Specifications
Conductor Size
18 AWG
Conductor Number
4
Diameter Over Conductor
0.045 inch (0.11 cm)
Insulation Thickness
15 mils (0.38 mm)
Jacket Thickness
65 mils (1.65 mm)
Approximate Outer Diameter
0.493 inch (1.25 cm)
Approximate Weight
133 lbs/1000' (198 kgs/km)
Minimum Bend Radius
5.9 inch (14.99 cm)
DC Resistance at 25°C
6.669 ohms/1000' (9.92 ohms/km)
Conductor Construction
Class B stranded bare copper per ASTM B3 and B8
Insulation Construction
Twisted pair with Premium Grade Polyvinyl Chloride (PVC)
Drain Wire Construction
Tinned copper
Twisted Shielded Pair Construction
100% coverage aluminum/polyester foil shield with individual drain wire
Binder Construction
Mylar binder
Overall Drain Wire Construction
Tinned Copper
Overall Shield Construction
100% coverage aluminum/polyester foil shield with drain wire
Rip Cord Construction
Rip cord under jacket
Jacket Construction
Black sunlight and moisture resistant Polyvinyl Chloride (PVC)
Outer Jacket Color
Black
Packaging
Cut to Length Reel
Specification Number
43303
Southwire Part Number
55841499
