Southwire 1180 4 Inch Pvc Type T Junction Box

Product Description

The SOUTHWIRE 1180 is a 4-inch PVC Type T junction box designed for use in conduit raceway systems. It provides a secure enclosure point for wire pulls, splices, and conduit transitions in electrical installations. The Type T configuration features three conduit entry points arranged in a T-pattern, making it well suited for branching runs. Constructed from PVC, the box offers corrosion resistance in environments where metal fittings may not be appropriate. Licensed electricians and electrical contractors are the primary installers of this fitting.

This junction box is used in commercial and residential electrical conduit systems where PVC conduit is the specified raceway material. Common applications include exposed or embedded conduit runs in concrete, underground installations, and corrosive or wet environments where non-metallic fittings are required. The 4-inch trade size accommodates larger conduit runs typical of feeder circuits and service entrance work.

Key Features

• Type T configuration provides three-way conduit branching in a single fitting
• PVC construction resists corrosion, moisture, and chemical exposure
• 4-inch trade size accommodates larger conduit and wire fills
• Designed for use in PVC conduit raceway systems
• Suitable for wet, damp, and corrosive environment installations

Compatibility

Designed as an OEM-style fitting for use with 4-inch schedule PVC conduit systems in standard electrical raceway installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code (NEC). De-energize all circuits before opening or working within any junction box. PVC solvent cement is typically required to secure conduit connections at each entry hub. Ensure the box is properly supported and that all conduit entries are sealed according to local code requirements for the installation environment.

Technical Specifications

• Trade Size: 4 inches
• Material: PVC
• Configuration: Type T
• Weight: 9 pounds
• UPC: 75133823239

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 1180
