Southwire 10750108 Mc Cable 14AWG 4C 600V 250ft Reel

Product Description

The SOUTHWIRE 10750108 is a metal-clad (MC) cable rated at 600 volts, built with 14 AWG stranded copper conductors in a 4-conductor configuration. MC cable carries circuit wiring inside a flexible interlocked aluminum armor, providing mechanical protection without the need for conduit in many applications. This product ships on a 250-foot reel, making it practical for larger commercial or residential rough-in jobs. Licensed electricians and electrical contractors install this type of cable in branch circuit wiring where an armored, code-compliant solution is required.

This MC cable is suited for use in dry, wet, or damp locations depending on the listed jacket rating, and is commonly pulled in residential, light commercial, and industrial construction. The 14 AWG conductor size is standard for 15-amp branch circuits. The 4-conductor layout supports multi-wire branch circuits, switch-leg wiring, or equipment requiring a dedicated neutral and ground path. A 250-foot reel reduces the number of splices needed on larger runs and keeps job-site material organized.

Key Features

• 600-volt rating suitable for standard branch circuit applications
• 14 AWG stranded copper conductors for flexibility during installation
• 4-conductor configuration supports multi-wire and equipment circuits
• Metal-clad armor provides mechanical protection without separate conduit
• 250-foot reel format reduces mid-run splices on longer cable runs

Compatibility

Designed as a standard MC cable replacement or new-install product for 15-amp, 600-volt branch circuits in residential and light commercial electrical systems.

Installation Notes

Installation must be performed by a licensed electrician in accordance with the National Electrical Code (NEC), Article 330. De-energize and lock out the circuit panel before terminating conductors. An MC cable cutter or rotary armored cable cutter is the appropriate tool for cutting the aluminum jacket cleanly without nicking conductor insulation. Anti-short bushings must be installed at all termination points where the armor is cut.

Technical Specifications

• Conductor Size: 14 AWG
• Number of Conductors: 4
• Conductor Type: Stranded Copper
• Voltage Rating: 600 volts
• Cable Length: 250 feet
• Armor Type: Metal-Clad (MC) Interlocked Aluminum

Standard Information

• Brand: SOUTHWIRE
• Manufacturer Part Number: 10750108
