Southwark Metal ATTRP6 Air-Tite Saddle Takeoff 6 in

Product Description

Southwark Metal ATTRP6 is a 6 in Air-Tite saddle takeoff designed to provide an airtight branch connection to round ductwork or pipe. The ATTRP6 is constructed of 26 gauge steel with a hot-dipped galvanized finish and includes a neoprene foam gasket for a sealed collar connection. The fitting features a 1/2 in overlap with 1/8 in rivets, an RL-2 rivet seam, a 1-1/4 in L crimp and a tube length range of 5-3/4 to 14-3/4 in.

• 26 gauge steel construction with hot-dipped galvanized finish for corrosion resistance
• Air-Tite saddle design: 1/2 in overlap with 1/8 in rivets, RL-2 rivet seam (+/-4 in WG) and 1-1/4 in L crimp
• Neoprene foam gasket (1-1/2 in W x 1/8 in THK) with four 1/8 in holes for sheet metal screw attachment; tube length 5-3/4 to 14-3/4 in

Product Highlights

6 in Air-Tite round saddle takeoff; 26 ga steel; hot-dipped galvanized finish; neoprene foam gasket for sealed branch connections

Product Information

Standard Information

• Brand: SOUTHWARK METAL
• Manufacturer Part Number: ATTRP6

Technical Specifications

• Brand: Southwark Metal
• Manufacturer: Southwark Metal Manufacturing
• Manufacturer Part Number: ATTRP6
• Model / Series: ATTRP
• Part Type: Air-Tite saddle takeoff
• Description: Air-Tite round pipe saddle takeoff
• Size: 6 in
• Shape: Round
• Material: Steel
• Gauge: 26 ga
• Finish: Hot-dipped galvanized
• Weight: 2.0 lb
• UPC: 09927352893
• Overlap: 1/2 in overlap with 1/8 in rivets
• Rivet Seam: RL-2 rivet seam (+/-4 in WG)
• Crimp: 1-1/4 in L crimp
• Tube Length Range: 5-3/4 to 14-3/4 in
• Gasket: 1-1/2 in W x 1/8 in THK neoprene foam, adhesive-coated
• Gasket Attachment: Four 1/8 in holes for sheet metal screw attachment
• Compatible Pipe Size: 6 in
