SMC VR1210F-04 Shuttle Valve with One-touch Fit

Product Description

The SMC VR1210F-04 is a reliable shuttle valve with a one-touch fitting. This component is designed for use in pneumatic systems where efficient flow control is needed. The valve operates efficiently under a range of pressures, making it suitable for various applications.

• Shuttle valve with one-touch fitting
• Maximum operating pressure: 1MPa (145 psi)
• Temperature range: -5°C to 60°C (23°F to 140°F)

Product Highlights

This shuttle valve is an essential part of many pneumatic setups. It is designed to operate efficiently while being easy to install and use.

Product Information

Standard Information

• Manufacturer: SMC
• Part Number: VR1210F-04

Technical Specifications

• Body Size: 1 (1/8 Basis)
• Applicable Tube OD: 4 mm
• Port Size: 4 mm Push-to-Connect
• Port Gender: Female
• Body Material: Aluminum Alloy
• Seal Material: Nitrile
• Overall Height: 32.2 mm
• Overall Length: 56 mm
• Proof Pressure: 1.5 Mpa
• Operating Pressure Range: 0.05 to 1 Mpa
• Operating Temperature Range: -5 to +60 °C
• Flow Coefficient (Cv): 3.2 mm²
