SMC KQ2U07-00A KQ2 Union 1/4 in Nominal Push-In End Style

Product Description

The SMC KQ2U07-00A is a union fitting designed for efficient connection in pneumatic systems. With a nominal size of one-fourth inch, this fitting allows push-in installation for quick setup. The KQ2 series includes features that support various application needs.

• Accepts nylon and polyurethane tubes.
• Stud design allows rotation for easy installation in tight spaces.
• Release collar simplifies tubing removal without damage.

Product Highlights

This fitting is suitable for a wide range of pressures, from low vacuum to one megapascals. It is not intended for use in potable water systems. The SMC KQ2U07-00A operates effectively within a temperature range of negative five to sixty degrees Celsius.

Product Information

Standard Information

• Brand: SMC
• Part Number: KQ2U07-00A

Technical Specifications

• Color: White
• Material: Brass
• Finish: Nickel Plated
• Length: 38 mm
• Dimensions: 0.52 in Diameter
• Operating Pressure Range: -100 kPa to +1 MPa
• Compatible Tube Outer Diameter: 1/4 in
• Max Operating Temperature: +40 °C (Water), +60 °C
• Min Operating Temperature: -5 °C
