SMC KQ2H10-12A KQ2 Union One-Touch Fittings 10 x 12 mm

Product Description

The SMC KQ2H10-12A is a union one-touch fitting designed for connecting tubes in pneumatic systems. This fitting features a nominal size of ten by twelve millimeters and a push-in end style. It is constructed from durable brass and operates effectively under various pressures and temperatures.

• Accepts multiple tube types including FEP, PFA, nylon, and polyurethane.
• Operating pressure range from -100 kPa to 1 MPa.
• Easy tube removal with the release collar feature.

Product Highlights

This fitting is suitable for applications requiring quick and reliable connections in pneumatic systems.

Product Information

Standard Information

• Brand: SMC
• MPN: KQ2H10-12A

Technical Specifications

• Material: Brass
• Nominal Size: 10 x 12 mm
• Pressure Rating: -100 kPa to 1 MPa
• Length: 33.6 mm
• Temperature Rating: -5 to 60 deg C Air, 0 to 40 deg C Water Operating
• End Style: Push-In
• Fitting/Connector Type: Connector
• Country of Origin: JP
