Smart Electric SE4540-O Single Oval Run Capacitor 45 MFD 440 V

Product Description

The Smart Electric SE4540-O is a single oval run capacitor. It is perfect for general replacements and features small dimensions. This capacitor is non-PCB and utilizes a polypropylene film medium and metalized film electrode. The capacitor has an aluminum case and is filled with plant oil, in accordance with UL standards.

• Available round or oval
• Widest selection of ratings in the industry
• Perfect for general replacements, small dimensions available

Product Highlights

Single oval run capacitor ideal for general replacements. Features polypropylene film, metalized film electrode, and an aluminum case.

Product Information

Standard Information

• Brand: SMART ELECTRIC
• Manufacturer Part Number: SE4540-0

Technical Specifications

• Capacitor Shape: Oval
• Medium: Polypropylene Film
• Electrode: Metalized Film
• Case Material: Aluminum
• Filling Material: Plant oil (in accordance with UL)
• Expected Life: 60,000 Hours
• Rated Voltage: 440 Vac
• Max permit temperature: 85° C/185° F
• Standards: UL 810, IEC 60252-1, EIA456-A
