Sloan 0345125 EL-451 Box Mount Transformer 120 VAC Input 6 VAC Output 25 VA

Product Description

The Sloan EL-451 transformer, MPN 0345125, is a box-mount transformer that operates with PWT systems. It is rated for 25 VA output and features a 120 VAC input with a 6 VAC output. This transformer is recommended for use with multi-combination units of urinals or closet sensor flush valves. The box-mount design allows easy installation and efficient use in commercial settings.

• Box-mount design for easy installation
• Operates with up to 8 units
• Class II, UL Listed for safety

Product Highlights

This transformer is essential for powering various configurations of flush valves in commercial restroom facilities.

Product Information

Standard Information

• Brand: Sloan
• MPN: 0345125

Technical Specifications

• Input Voltage: 120 VAC
• Output Voltage: 6 VAC
• Rating: 25 VA
• Weight: 1.33 pounds
• Shipping Dimensions: 4 inches x 4 inches x 4.75 inches
• Power Capacity: Operates up to 8 units
• Category: Miscellaneous Parts
• Commercial Use: Primarily for commercial applications
