SKF P2BE 80M-TRB-STH | Cylindrical Bore Standard Duty Pillow Block

Product Description

SKF P2BE80M-TRB-STH is a cylindrical bore standard duty pillow block designed for reliable and consistent performance. This pillow block features an eighty millimeter shaft diameter and is ideally suited for various mechanical applications.

• Standard-duty mounted unit
• Tapered roller bearing design
• Pillow block with two bolt holes

Product Highlights

This pillow block offers robust support and is engineered for durability in demanding environments.

Product Information

Standard Information

• Brand: SKF
• Part Number: 118050717

Technical Specifications

• Mounted Unit Duty: Standard-Duty
• Bolt Hole Spacing Range [Max]: 300.04 mm
• Bolt Hole Spacing Range [Min]: 274.64 mm
• Bearing Type: Tapered Roller Bearing
• Length Through Bore: 127 mm
• Shaft Diameter: 80 mm
• Dynamic Load Rating: 19000 lbf
• Relubricatable: Yes
• Bolt Size: 22.23 mm
• Seal Type: Contact
• Housing Length: 355.6 mm
• Locking Device: Double Set Screw
• Bolt Holes: 2
• Bore Type: Cylindrical Bore
• Pillow Block Type: 2-Bolt
• Housing Material: Cast Iron
• Inch/Metric: Metric
• Lubrication: Grease
• Seal Material: Hydrogenated Nitrile Rubber (HNBR)
• Weight: 49.37 LB
• EAN or UPC: 7316579540988
