Sioux Chief 672WG06C0 Manifold 6-port Cpvc F1960

Product Description

The SIOUX CHIEF 672WG06C0 is a closed-end plumbing manifold designed for residential and light commercial water distribution systems. Built to 1 inch inlet sizing with CPVC construction, this manifold features six 1/2 inch F1960 PEX expansion ports and a closed outlet configuration. It is lead-free compliant, meeting current potable water standards for domestic plumbing installations. Licensed plumbers use this manifold as the central distribution point in home-run PEX systems, routing individual supply lines to fixtures without the pressure loss associated with teed branch layouts. The F1960 cold-expansion port standard ensures a reliable, insert-free connection method.

This manifold is suited for residential new construction and renovation plumbing projects where a structured, home-run distribution layout is specified. The six-port configuration accommodates typical single-zone installations supplying multiple fixtures from one central location. The CPVC body is compatible with potable hot and cold water service and performs in both supply and recirculation line layouts where manifold-style distribution is required. Installation is handled by licensed plumbers working under applicable plumbing codes such as the IPC or local adopted equivalents.

Key Features

• 1 inch inlet by 1/2 inch F1960 PEX expansion port configuration
• Six outlets for home-run distribution to individual fixtures
• Closed-end body eliminates need for an additional end cap
• Lead-free CPVC construction meets potable water compliance requirements
• F1960 cold-expansion connections require no insert fittings or clamps at the port

Compatibility

Designed as an OEM-style replacement or new-installation manifold for residential and light commercial PEX home-run plumbing systems using 1/2 inch F1960 expansion-style PEX tubing.

Installation Notes

Installation is performed by a licensed plumber in accordance with local adopted plumbing codes. Shut off the main water supply and depressurize the system before making any connections. F1960 expansion connections require an expansion tool sized for 1/2 inch PEX and the appropriate F1960 expansion ring. Support the manifold securely to prevent stress on branch lines after installation.

Technical Specifications

• Inlet Size: 1 inch
• Port Size: 1/2 inch
• Number of Ports: 6
• Connection Type: F1960 PEX Expansion
• End Configuration: Closed
• Material: CPVC
• Lead-Free: Yes
• UPC: 739236412287

Standard Information

• Brand: SIOUX CHIEF
• Manufacturer Part Number: 672WG06C0
