Simpson Strong Tie LS30 Adjustable L Angle

Product Description

The SIMPSON STRONG TIE LS30 is an adjustable L angle connector used in light framing and general construction applications. It is fabricated from 18 gauge galvanized steel and provides a flexible connection point that can be bent from a flat 0 degrees to 135 degrees, accommodating a range of framing angles in a single hardware piece. Licensed contractors and experienced framers install this connector where a rigid fixed angle bracket would not suit the required geometry. Installation is completed using six 10D nails, and the galvanized finish provides corrosion resistance for both interior and exterior use.

The LS30 is suited for residential and light commercial wood-frame construction. It is commonly used at rafter-to-plate connections, header framing, and other structural junctions where the framing angle varies from project to project. The adjustable design reduces the need to stock multiple fixed-angle connectors. It is sold in a package quantity of 100 pieces, making it appropriate for production framing crews and supply orders where volume is required.

Key Features

• Adjustable from 0 degrees to 135 degrees to fit variable framing angles
• 18 gauge galvanized steel construction for corrosion resistance in interior and exterior environments
• Installs with six 10D nails for a secure, code-compatible connection
• Single connector replaces multiple fixed-angle brackets across varied framing conditions
• Sold in 100-piece packages to support production framing and bulk procurement

Compatibility

Designed as an OEM-style structural connector for use in standard dimensional lumber wood-frame construction applications.

Installation Notes

Installation is typically performed by licensed framers or general contractors in accordance with applicable building codes. Fasten with six 10D nails as specified for the connector to develop its rated load capacity. Do not substitute smaller nails or reduce nail count, as doing so affects structural performance. Inspect the connector for damage or deformation before installation; do not install bent or compromised hardware.

Technical Specifications

• Material: 18 gauge galvanized steel
• Adjustment Range: 0 degrees to 135 degrees
• Fastener Requirement: Six 10D nails
• Package Quantity: 100 pieces per package
• Weight: 19 pounds
• Unit of Measure: Each (EA)

Standard Information

• Brand: SIMPSON STRONG TIE
• Manufacturer Part Number: LS30
