Siemens NEG3B045L VL Series Low Voltage Molded Case Circuit Breaker 240 VAC 45 A

Product Description

The Siemens NEG3B045L VL Series low voltage molded case circuit breaker with lugs operates at 240 VAC with a 45 A amperage rating and an 85 kA interrupt rating. It is a 3-pole breaker suitable for various electrical protection applications.

• ARRA Compliant
• Buy American Compliant
• Line/Load Connection

Product Highlights

This Siemens circuit breaker is designed for low voltage systems and offers reliable circuit protection with a thermal-magnetic trip type.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: NEG3B045L
• Country of Origin: DO

Technical Specifications

• Catalog Number: NEG3B045L
• Connection Type: Line/Load
• Country of Origin: DO
• Frequency Rating: 50/60 Hz
• Frame: NEG
• Number Of Poles: 3
• Phase: 3 pH
• Series: VL Series
• Standard: UL/CSA/IEC/NOM
• Temperature Rating: 50 �C
• Type: Low Voltage
• UNSPSC: 39121601
• Brand: Siemens
• Manufacturer: Siemens
• Amperage Rating: 45 A
• Interrupt Rating: 85 kA
• Trip Type: LI/Thermal Magnetic
• Voltage Rating: 240 VAC
• Model Number: NEG3B045L
• Group: Circuit Breakers
• Amperage: 45
• Classification: Molded Case
