Siemens HGB3B060B HGB Circuit Breaker 60A 3P 480Y HGB3B060B

Product Description

The Siemens HGB3B060B is a low voltage panelboard mount G frame circuit breaker. It has a thermal-magnetic trip and is UL listed. This breaker can handle up to sixty amps and is three pole. This model has a high breaking capacity, rated at fourteen kAIC at six hundred volt and thirty-five kAIC at four hundred eighty volt.

• Siemens brand quality
• High breaking capacity
• UL listed for safety

Product Highlights

The Siemens HGB3B060B is ideal for industrial applications and is designed for panelboard mounting. It features load side lugs only with a wire range accommodating eight to one/zero AWG copper or aluminum wires. Compact dimensions make it easy to fit into various setups.

Product Information

Standard Information

• Brand: Siemens
• Manufacturer: Siemens

Technical Specifications

• Catalog Number: HGB3B060B
• Frame: 125 A
• Voltage: 480 Volt
• Amperage: 60 Amp
• Material: Molded case circuit breaker
• Standard: UL/CSA/IEC/NOM
• Frequency: 50/60 Hz
• Trip Type: Thermal magnetic trip unit
• Interrupt Rating: 35 kAIC
• Number of Poles: 3
• Operating Temperature: 40 °C
• Country of Origin: Mexico
