Siemens HG61234 Siemens Low Voltage VBII Safety Switch, Ground Lug Kit, 600V, 30A to 200A

Product Description

The Siemens HG61234 is a ground lug kit designed for low voltage VBII safety switches. This kit supports a voltage rating of six hundred volts and handles current ratings from thirty amps to two hundred amps. It is suitable for both general and heavy-duty switches. The ground lug kit is a field installable solution for Type 1 and Type 3R switches. For Type 4, 4X, and Type 12 switches, this kit comes factory installed. It is also compatible with all VBII four and six pole switches.

• Compatible with Type 1 and Type 3R switches
• Factory installed in Type 4, 4X, and 12 switches
• Handles conductor sizes from 14 AWG to 2 AWG

Product Highlights

The Siemens HG61234 ground lug kit offers a reliable solution for electrical connections in safety switches, ensuring proper grounding and compliance with electrical standards.

Product Information

Standard Information

• Manufacturer: Siemens Industry
• Stock Code: 0215-8779

Technical Specifications

• UPC: 783643173828
• Type: Ground Fittings
• Length: 6.2 inches
• Width: 4.1 inches
• Height: 0.1 inches
• Weight: 0.066 pounds
• Insulated: No
• Connection: Screw terminal
• Country of Origin: MX
