Siemens ED63A003 Sentron Molded Case Circuit Breaker 3A

Product Description

The SIEMENS ED63A003 is a low voltage Sentron molded case circuit breaker with magnetic trip. This standard range ETI breaker features an ED frame with standard breaking capacity and meets UL 489 / IEC 60947-2 standards. Rated at 3A, this 3-pole breaker offers 18kAIC at 600V and 25kAIC at 480V. It is designed for standard range ETI breaker applications.

• Meets UL 489 / IEC 60947-2 standards
• Load lugs accommodate 14 - 10AWG (Cu) / 12 - 10AWG (Al) wire
• All ED frame circuit breakers may be reverse connected

Product Highlights

The SIEMENS ED63A003 circuit breaker is suitable for various electrical protection applications. It features a thermal-magnetic trip and is HACR rated.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: ED63A003
• Country of Origin: Mexico

Technical Specifications

• Catalog Number: ED63A003
• Manufacturer: Siemens
• Brand: Siemens
• Sub Brand: Sentron
• Country of Origin: Mexico
• Actuator: Varying
• Application: Standard Range ETI Breaker
• Enclosure: Varying
• Frame: ED
• Frequency Rating: 50/60 HZ
• Interrupt Rating: 18KAIC
• Number of Poles: 3
• Standard: HACR
• UPC: 783643210806
• GTIN: 00783643210806
• Trip Type: Thermal-Magnetic
• Voltage Rating: 600//250
• Product Type: CIRCUIT_BREAKER
• Trip Range: 10-35
