Siemens 49SPL0BGF Pilot Lite "FB" Green

Product Description

The SIEMENS 49SPL0BGF pilot light indicates operational status with a green "FB" indication. Designed for a 120V supply, this transformer-type pilot light features a plastic lens and an incandescent lamp. It is suitable for panel mounting and endures environmental conditions from -31 to 158 deg F operating and -40 to 185 deg F storage.

• Green "FB" indication
• Operates on 120V AC
• Panel mounting

Product Highlights

The pilot light is designed for clear indication and reliable performance in various environments.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 49SPL0BGF
• Country of Origin: Mexico

Technical Specifications

• Brand: SIEMENS
• Manufacturer Part Number: 49SPL0BGF
• Product UPC: 78308718056
• Supply Voltage: 120 V
• Terminal Type: Screw
• Lens Color: Green
• Lens Material: Plastic
• Enclosure Type: NEMA 1/3/3R/4/12/13
• Voltage Rating: 120 V AC
• Type: transformer
• Mounting Type: Panel
• Environmental Conditions: -31 to 158 deg F Operating, -40 to 185 deg F Storage, 5 to 60 Hz, 5.5 g Resistance Against Vibration Per IEC 60068-2-6
• Lamp Type: Incandescent
• Sold as: EACH
• Kit Type: Pilot Light
• Pilot Lights: 120V, Green ON
