Siemens 49SAP05 Pushbutton Switch

Product Description

The SIEMENS 49SAP05 is a pushbutton switch designed for use in industrial control and automation applications. Compact in size at 1.087 inches long, 0.496 inches wide, and 0.402 inches deep, this pushbutton integrates into control panels, operator interfaces, and machinery enclosures where space is limited. Weighing 0.794 pounds, it is built for straightforward installation in both new equipment and field replacement scenarios. Electricians and control panel technicians working on industrial or commercial systems will find this part a direct-fit replacement for failed or worn pushbutton assemblies.

This pushbutton is suited for industrial control panels, machine operator stations, and related electrical enclosures. It is packaged as one unit per pack. Typical applications include start, stop, or function actuation on motor control centers, automated equipment, and process control panels in commercial and industrial environments.

Key Features

• Compact footprint at 1.087 x 0.496 x 0.402 inches for space-constrained panel installations
• Lightweight at 0.794 pounds for easy handling and single-technician installation
• Single unit per pack for precise quantity ordering
• SIEMENS OEM part number 49SAP05 for direct replacement confidence

Compatibility

Designed as an OEM-style replacement pushbutton switch for SIEMENS industrial control and automation equipment requiring the 49SAP05 configuration.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and all applicable local codes. De-energize and lock out the panel or equipment before removing the existing pushbutton or installing this unit. Verify the mounting cutout and operator interface dimensions match prior to final installation. Do not apply power to the circuit until all wiring connections are secured and the enclosure is properly closed.

Technical Specifications

• Length: 1.087 inches
• Width: 0.496 inches
• Height: 0.402 inches
• Weight: 0.794 pounds
• Package Quantity: 1 per pack
• UPC: 78308708936

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 49SAP05
