Product Description
The Siemens 3VA4170-4ED24-0AA0 is a low voltage molded case circuit breaker featuring a thermal-magnetic trip unit. This device is designed for reliable power distribution and protection in electrical systems.
- 70 Amps, 2 poles configuration
- Interruption ratings of 14 kA at 600Y/347V and 25 kA at 480V
- Dimensions of five point five inches high, two inches wide, and three point seven inches deep
Product Highlights
The circuit breaker includes fixed current ratings and specialized lugs installed on the load side only.
Product Information
Standard Information
-
Brand: Siemens
-
Catalog Number: 3VA4170-4ED24-0AA0
Technical Specifications
-
Amperage Rating: 70 A
-
Connection Type: Aluminum Wire/Load End/Lug
-
Dimensions: 5.5 in H x 2 in W x 3.7 in D
-
Enclosure Type: IP40
-
Frame: 125/150 A
-
Frequency Rating: 50/60 Hz
-
Interrupt Rating: 14 kA, 25 kA, 65 kA
-
Number of Poles: 2
-
Series: 3VA41
-
Temperature Rating: -25 to 70 deg C
-
Trip Range: 70 to 700 A
-
Trip Type: TM210 Thermal Magnetic
-
Type: Class S Standard Low Voltage
-
Wire Size: 8 to 3/0 AWG
