Product Description
The Siemens 3VA4150-4ED24-0AA0 is a low voltage molded case circuit breaker with a thermal-magnetic trip unit. This unit is designed with a frame size from the 3VA41 series and provides a standard breaking capacity. It operates at fifty amperes and has two poles, delivering reliable protection in various applications.
- 50 Amperes, 2-Pole setup
- Interrupt ratings of 14 kA at six hundred volts and 25 kA at four hundred eighty volts
- Compact dimensions for easy installation
Product Highlights
This circuit breaker features lugs installed on the load side only and comes with a TM210 trip unit that has fixed settings, ensuring precise performance and safety.
Product Information
Standard Information
-
Brand: Siemens
-
Type: Class S Standard Low Voltage
Technical Specifications
-
Amperage Rating: 50 A
-
Connection Type: Aluminum Wire/Load End/Lug
-
Dimensions: 5.5 in H x 2 in W x 3.7 in D
-
Enclosure Type: IP40
-
Frame: 125/150 A
-
Frequency Rating: 50/60 Hz
-
Interrupt Rating: 14 kA, 25 kA, 65 kA
-
Number of Poles: 2
-
Series: 3VA41
-
Temperature Rating: -25 to 70 deg C
-
Trip Range: 50 to 500 A
-
Trip Type: TM210 Thermal Magnetic
-
Wire Size: 8 to 3/0 AWG
