Siemens 3RT20171KB41 Coupling Relay S00 12A 24VDC 1NO

Product Description

The SIEMENS 3RT20171KB41 is a coupling relay, AC-3, with 5.5KW/400V, and 1NO contact. It operates on DC 24V with 0.7...1.25*us voltage and includes a plugged-on varistor. This 3-pole size S00 relay features a screw terminal for secure connections. It is suitable for various industrial applications requiring reliable switching.

• RoHS Compliant
• Auxiliary Contacts
• CCC, CSA, UL, KC, EAC, RCM, CE, VDE, ABS, BUREAU VERITAS, Lloyds Register, PRS, RINA, RMRS, DNV-GL, WEEE (2012/19/EU) Certified

Product Highlights

The SIEMENS 3RT20171KB41 coupling relay ensures efficient and safe operation with its robust design and multiple certifications.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RT20171KB41
• Country of Origin: DE

Technical Specifications

• UNSPSC Code: 39120000
• Auxiliary Contact: 1 NO
• Brand: SIEMENS
• Contact Current Rating: 12 A
• Control Voltage: 24 V
• Manufacturer Part Number: 3RT20171KB41
• Mounting Type: DIN Rail Mount
• Number of Poles: 3
• Terminal Type: Screw Terminal
• Type: Coupling Contactors
• UPC Code: 662643911329
• Category: Relays
• Switching Voltage: 690VAC - Max
• Manufacturer: Siemens
• Features: Auxiliary Contacts
• Series: SIRIUS
• Operating Temperature: -25 C ~ 60 C
• Part Status: Active
• Must Operate Voltage: 16.8 VDC
• Operate Time: 130 ms
• Coil Voltage: 24VDC
• Release Time: 20 ms
• Contact Form: 3PST-NO (3 Form A)
• Coil Power: 2.8W
• Contact Rating (Current): 12 A
• Base Product Number: 3RT2017
• Part Number #: 3RT20171KB41
• Contact Rating: A600/Q600
• Enclosure Type: IP20
• Temperature Rating (Degrees F): -25 to 60 deg C
• Country of origin: DE
• Mounting type: DIN Rail/Snap-On/Threaded
• Manufacturer Name: Siemens
• UNSPSC: 39121529
