Siemens 3RF2440-1AB45 Solid State Contactor 40A

Product Description

The SIEMENS 3RF2440-1AB45 is a solid-state contactor with a 40A maximum load current. This 3-phase zero point switching contactor is part of the 3RF series and operates between 48 to 600 VAC with a 4 to 30 VDC coil. It features a screw terminal and IP20 enclosure, suitable for DIN rail mounting.

• Zero point switching
• Maximum load current of 40A
• Operating temperature of -25 to 60 deg C

Product Highlights

Solid state contactor with zero point switching and a wide voltage range.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 3RF2440-1AB45
• Country of Origin: China

Technical Specifications

• Brand: Siemens
• Model: 3RF2440-1AB45 3RF2 440-1AB45
• Voltage (V): 48-600 V / 4-30 V DC
• UL Listed: CSA,UL,EAC
• GTIN: 00040892554069
• UNSPSC: 39121529
• Country of Origin: Germany
• Contact Configuration: 3NO
• Enclosure Type: IP20
• Frequency Rating: 50/60 Hz
• Maximum Load Current: 40 A
• Mounting Type: DIN Rail
• Number of Poles: 3
• Operating Temperature: -25 to 60 deg C
• Series: 3RF
• Terminal Type: Screw
• Type: 3-Phase Zero Point Switching
• BABA Compliant: No
• Coil Voltage: 48 to 600 V AC, 4 to 30 V DC
• Product Family: Siemens SIRIUS 3RF2 Solid-State Contactors
