Siemens 14EUE32AJ Starter, FVNR SZ1 3/4, 10-40Amps, Open, 24V

Product Description

The SIEMENS 14EUE32AJ is a heavy-duty full voltage non-reversing starter. This open-type starter features a NEMA size of 1 3/4 and an overload range of 10-40 Amps. It is designed for motor control applications, with a coil voltage of 24V AC and suitable for use with motors up to 15 hp at 460V. The unit has solid-state overload relay and screw terminal connections.

• Rugged industrial design
• Half sizes for cost and space savings
• Dual voltage and dual frequency coils

Product Highlights

Heavy-duty, full voltage non-reversing starter with solid-state overload relay and open enclosure. Suitable for motor control applications requiring reliable performance.

Product Information

Standard Information

• Brand: SIEMENS
• Manufacturer Part Number: 14EUE32AJ
• Country of Origin: Mexico

Technical Specifications

• Enclosure: Open Type
• Nema Size: 1 3/4
• Overload Range: 10-40
• Max HP at 200 V: 10
• Max HP at 230 V: 10
• Max HP at 460 V: 15
• Type: Heavy Duty Full Voltage Non-Reversing
• Construction Standard: NEMA 600V AC
• Size: NEMA Half Size 1-3/4
• UL Cont. Amps: 40A
• Phase: 3
• Coil Voltage: 24 V AC
• Motor Power: 10 hp at 200/208/220/230 VAC, 15 hp at 460/480/575/600 VAC
• Hp 3-Phase 575V: 15 hp
• Enclosure Type: Open
• Overload Relay: Solid-State
• Motor FLA: 10.00-40.00A
• Auxiliary Contacts: (1) NO
• Number of Poles: 3
• Auxiliary Contact Rating: 10 A at 600 VAC, 5 A at 600 VDC
• Operating Temperature: -20°C ~ 40°C
• Frequency Rating: 60 Hz
• Voltage Rating: 600 V AC
• Full Load Current: 10 to 40 A
• Connection Type: Screw Terminal
• Reset Type: Automatic/Manual/Remote
• Amperage Rating: 40 A
• Operating Cycles: 10000000 Cycles
• Voltage - Load: 600V
• Current - Output: 40A
• Wattage - Load: 11190 W
• Voltage - Supply: 24VAC
• Mounting Type: Chassis Mount
