Sharkbite/cash Acme 10YE52V024B Brass Gas Ball Valve

Product Description

The SHARKBITE/CASH ACME 10YE52V024B is a 1/2-inch OD flare by 1/2-inch FIP brass gas ball valve rated for service with natural gas, liquid propane gas, and air mixtures up to 175 psi. The body is full brass construction for corrosion resistance and a durable, leak-resistant connection. An aluminum lever handle provides quarter-turn on/off flow control, and large wrench flats simplify installation and future service work. This valve installs inline between two pipes running in the same direction, connecting a 1/2-inch OD gas connector on one end to a 1/2-inch male iron pipe supply on the other.

This valve is suited for residential and light commercial gas supply applications where a reliable shutoff is needed between the gas supply line and an appliance or connector. Typical installations include gas range hookups, dryer connections, water heater supplies, and similar natural gas or propane appliance service points. The quarter-turn operation allows a technician to quickly isolate the appliance during service or in an emergency. It is installed by licensed plumbers or gas fitters working to applicable code requirements.

Key Features

• Rated to 175 psi for natural gas, liquid propane, and air mixtures
• Full brass body construction for durability and corrosion resistance
• Quarter-turn aluminum lever handle for fast on/off flow control
• Large wrench flats for easier installation and removal
• Inline configuration connects two pipes running in the same direction
• 1/2-inch OD flare inlet connects to standard gas flexible connectors

Compatibility

Designed as an OEM-style replacement or new-installation gas shutoff valve for 1/2-inch OD flare gas connectors paired with 1/2-inch FIP pipe fittings in natural gas and liquid propane supply systems.

Installation Notes

Installation should be performed by a licensed plumber or qualified gas fitter in accordance with local codes and the International Fuel Gas Code (IFGC). Shut off the main gas supply and verify zero pressure at the work point before beginning any connection. Apply approved gas-rated thread sealant to all FIP connections and verify all flare connections are properly seated before restoring gas pressure. Leak-test all joints with an approved gas leak detection solution after installation.
