Sgs Pro 15403 Double Cut Carbide Bur SL-41 Taper

Product Description

The SGS PRO 15403 is a double cut tungsten carbide abrasive bur in the SL-41 taper profile with a ball nose cone head shape. It is designed for aggressive material removal and finishing work on ferrous and non-ferrous metals using a rotary tool or die grinder. The 1/8 inch shank fits standard collets on most pneumatic and electric die grinders. With a cutting diameter of 0.125 inches and an overall length of 1.5 inches, this bur is suited for detail work in tight areas. Maximum operating speed is 100,000 RPM. The uncoated tungsten carbide head delivers hardness and wear resistance across a wide range of materials.

This bur is used in metalworking, fabrication, maintenance, and toolroom applications. The SL-41 taper geometry with ball nose cone is well suited for deburring, port work, contour finishing, and material blending in recessed areas. It performs on steel, hardened steel, stainless steel, cast iron, titanium, nickel, copper, and copper alloys. Machinists, tool and die makers, welders, and maintenance technicians commonly use this style of bur for both production and repair work.

Key Features

• Double cut tooth style for fast material removal and smooth finish
• Tungsten carbide head construction for durability on hard materials
• SL-41 taper with ball nose cone profile for contour work and blending
• 1/8 inch shank diameter fits standard die grinder collets
• Rated to 100,000 RPM for high-speed rotary tool use
• Compatible with steel, hardened steel, stainless steel, cast iron, titanium, nickel, copper, and copper alloys

Compatibility

Designed for use with rotary die grinders and flex-shaft tools accepting a 1/8 inch collet. Suitable for metalworking applications requiring SL-41 taper geometry burs.

Installation Notes

This bur is installed and operated by machinists, fabricators, and maintenance technicians using pneumatic or electric die grinders. Confirm the collet size matches the 1/8 inch shank before mounting. Do not exceed the rated 100,000 RPM maximum speed. Always wear appropriate eye protection and secure the workpiece before operating.
