Sgs 91235 Corner Radius End Mill 1/4 in 2 Flute Carbide

Product Description

The SGS 91235 is a solid carbide corner radius end mill designed for high-performance material removal in non-ferrous metal applications. With a 1/4 inch mill diameter, 0.01 inch corner radius, and TiB2 (Ti-NAMITE-B) coating, this tool delivers consistent edge protection and extended tool life in aluminum, brass, copper, and similar workpiece materials. The 2-flute, right-hand spiral configuration promotes efficient chip evacuation, and the high helix angle at 45 degrees supports aggressive cutting in softer materials. It mounts in standard end mill toolholders via a straight cylindrical shank. Installation and operation are handled by machinists and CNC programmers in production and job shop environments.

The SGS 91235 is intended for short-reach roughing operations on non-ferrous metals. The single-end, centercutting geometry with a coarse pitch and high helix makes it well suited for slotting, profiling, and peripheral milling in CNC machining centers and manual knee mills. The 3/8 inch length of cut and 1 inch reach length keep deflection low in shallow-to-moderate pocket work. End mill toolholders with appropriate runout tolerances are the specified holding method for this tool.

Key Features

• TiB2 (Ti-NAMITE-B) coating resists built-up edge and extends life in non-ferrous materials
• 45-degree high helix angle promotes aggressive chip evacuation in aluminum and similar alloys
• 0.01 inch corner radius reduces stress concentration at the cutting edge and improves corner durability
• Micrograin solid carbide substrate provides rigidity and wear resistance
• Right-hand cut, right-hand spiral, single-end configuration for standard CNC and manual mill setups
• Straight cylindrical shank with h6 tolerance fits securely in collet and end mill toolholders

Compatibility

Designed for use with standard end mill toolholders. Primary workpiece material is non-ferrous metal. Part of the SGS Series 45C Ski-Carb 45 line.

Installation Notes

Installation is performed by a qualified machinist or toolroom technician. Ensure the machine spindle is fully stopped and locked out before changing tooling. Confirm toolholder runout is within acceptable limits before securing the shank, as excessive runout accelerates wear on carbide end mills. Follow machine tool manufacturer guidelines for feed rate and spindle speed when cutting non-ferrous materials at high helix angles.
