Sgs 31886 Square End Mill 0.5in 4-flute Altin Solid Carbide

Product Description

The SGS 31886 is a solid carbide square end mill designed for high-performance milling in demanding production environments. Built on the Series 1EL extra-long platform, it features a 0.5-inch cutting diameter, a 3-inch length of cut, and a 6-inch overall length, making it well-suited for deep-pocket and extended-reach milling operations. The tool carries an AlTiN coating for heat resistance and extended tool life at elevated cutting speeds. Four spiral flutes with a 30-degree helix angle and a variable index configuration promote smooth chip evacuation and reduce harmonic vibration during the cut. Micrograin carbide substrate adds wear resistance in abrasive materials. Installed by machinists and CNC operators in job shop and production environments.

This end mill is rated for use across a broad range of workpiece material categories, including hardened steels, cast irons, stainless and high-temperature alloys, aluminum and non-ferrous materials, plastics and composites, and superalloys. The extra-long flute length supports deep side-milling and slotting passes where standard-length tooling cannot reach. The straight-cylindrical shank with a tight shank diameter tolerance of +0.00000 to -0.00043 inches ensures consistent runout and secure clamping in standard end mill holders, collet chucks, and shrink-fit toolholders.

Key Features

• AlTiN coating for heat resistance and extended tool life at high cutting speeds
• 30-degree right-hand spiral flute geometry for efficient chip evacuation
• Variable index flute spacing reduces chatter and harmonic vibration
• Centercutting design allows plunge entry
• Micrograin solid carbide substrate for wear resistance in abrasive workpiece materials
• Extra-long Series 1EL platform with 3-inch length of cut for deep-reach applications

Compatibility

Rated for primary workpiece material categories H, K, M, N, P, and S, covering hardened steels, cast irons, stainless and high-temperature alloys, non-ferrous metals, plastics, and superalloys. Designed for use in standard 0.5-inch end mill holders, collet chucks, and shrink-fit tooling systems.

Installation Notes

Installation and setup should be performed by a qualified machinist or CNC operator. Ensure the machine spindle and toolholder are clean and free of debris before seating the shank. Verify runout with a dial indicator after clamping to confirm the shank tolerance is within acceptable limits for the application. Follow the toolholder manufacturer torque specifications when tightening set screws or collet nuts.
