Service Metal ser0602.5 Cs Butt Weld Eccentric Reducer 6x2.5

Product Description

The SERVICE METAL ser0602.5 is a standard eccentric reducer fitting designed for butt weld pipe installations in carbon steel piping systems. This fitting transitions from a 6-inch pipe diameter down to a 2.5-inch pipe diameter using an eccentric offset, which keeps one side of the pipe flat to prevent air pockets and allow for proper drainage. Weighing 6.6 pounds, it is built to standard dimensional tolerances for butt weld fittings. Licensed plumbers, pipefitters, and industrial piping contractors are the primary installers for this type of fitting.

Eccentric reducers like the ser0602.5 are used in commercial and industrial piping systems where maintaining a consistent bottom-of-pipe elevation is required. Common applications include pump suction lines, horizontal drain lines, and process piping where air entrapment or gravity drainage must be managed. This fitting suits carbon steel pipe installations in mechanical rooms, process plants, refineries, and heavy commercial construction.

Key Features

• Eccentric offset design prevents air pockets in horizontal piping runs
• Carbon steel butt weld construction for high-strength welded joints
• 6-inch to 2.5-inch transition in a single standard fitting
• Standard wall fitting for compatibility with schedule-matched pipe
• Import sourced, meeting standard dimensional requirements for butt weld fittings

Compatibility

Designed as a standard butt weld eccentric reducer for carbon steel pipe systems transitioning from 6-inch to 2.5-inch nominal pipe size.

Installation Notes

Installation requires a certified welder following applicable codes such as ASME B31.3 or ASME B31.1 depending on the service type. Shut down, depressurize, and purge the piping system before cutting or fitting. Use appropriate pipe alignment tools to maintain proper flat-bottom orientation for eccentric installation. Do not apply heat to the fitting outside of qualified welding procedures.

Technical Specifications

• Fitting Size: 6 inches x 2.5 inches
• Material: Carbon Steel
• Connection Type: Butt Weld
• Type: Eccentric Reducer
• Wall Standard: Standard
• Weight: 6.6 pounds
• Origin: Import

Standard Information

• Brand: SERVICE METAL
• Manufacturer Part Number: ser0602.5
