SEPCO ST10 1/2-Inch Polypropylene Insulated Plastic Bushing

Product Description

The SEPCO ST10 is a 1/2-inch polypropylene insulating bushing designed for threaded rigid and IMC conduit applications. This bushing is constructed from flame-retardant thermoplastic material, providing resistance to heat, impact, and torque. It features a smooth bearing surface for wires and cables at the end of threaded conduit or conduit connectors. Its threaded connection type ensures secure installation.

• Constructed from durable thermoplastic for resistance to heat and impact.
• Rated to a maximum temperature of 221°F (105°C).
• Suitable for use with threaded rigid and IMC conduits.

Product Highlights

The SEPCO ST10 bushing is UL Listed under E198258 and meets CSA specifications, making it a reliable choice for electrical installations.

Product Information

Standard Information

• Brand: SEPCO
• Manufacturer Part Number: ST10

Technical Specifications

• Trade Size: 1/2 Inch
• Outside Diameter: 1.03 inches
• Connection Type: Threaded
• For Use With: Threaded Rigid/IMC Conduit
• Temperature Rating: Rated to 221°F (105°C)
• Material: Flame-Retardant Polypropylene
• Color: Lime, Grey, Blue
• Country/Region of Manufacture: United States
