Security Door Controls ptm-10bz Power Transfer Device

Product Description

The SECURITY DOOR CONTROLS ptm-10bz is a heavy-duty electric power transfer device designed to route electric lock and exit device power and signal wiring through a door frame without exposed cabling. It carries ten 24-gauge conductors and features a dark brown powder coat finish. The device mounts concealed within the door hinge area so that all wiring is fully hidden when the door is closed. Licensed locksmiths, access control technicians, and door hardware installers work with this type of device on commercial and institutional openings.

The ptm-10bz is suited for high-traffic commercial doors where concealed wiring is required for electric strikes, electromagnetic locks, exit devices with electric latch retraction, or door position and request-to-exit signals. Its design resists tampering and physical abuse, making it appropriate for applications with elevated security requirements. The concealed routing eliminates the looped wire harnessing or surface-mounted raceways common on less secure installations.

Key Features

• Ten 24-gauge conductors provide capacity for power and multiple signal circuits in a single transfer device
• Fully concealed when the door is closed, reducing tamper risk and improving aesthetics
• Dark brown powder coat finish suited for bronze-hardware door sets
• Heavy-duty construction rated for high-traffic and high-security openings
• Designed for use with electric locks, exit devices, and access control signal wiring

Compatibility

Designed as an OEM-style replacement or new-installation power transfer device for commercial doors equipped with electric locking hardware, exit devices, or access control wiring requiring frame-to-door conductor transfer.

Installation Notes

Installation should be performed by a licensed door hardware technician or access control specialist familiar with electric hardware and applicable building codes. De-energize all connected electric locking and access control hardware before installation or service. Verify conductor routing and connection integrity before returning the door to service. Consult the manufacturer installation instructions for mortise depth and edge preparation requirements specific to the door and frame material.

Technical Specifications

• Number of Conductors: 10
• Wire Gauge: 24 AWG
• Finish: Dark Brown Powder Coat

Standard Information

• Brand: SECURITY DOOR CONTROLS
• Manufacturer Part Number: ptm-10bz
