Seco SECOT-34042 MDT Single End Turning Insert, ANSI Code: LCGN1603-A60 CP500

Product Description

The Seco SECOT-34042 MDT Single End Turning Insert is a precision tool designed for external threading applications. This turning insert features a rectangular shape and is suitable for use on stainless steel materials. It's made from carbide and has a material grade classified as M.

• Designed for external threading applications
• Carbide construction with PVD-TiAlN+TiN coating
• Compatible with stainless steel for efficient cutting

Product Highlights

This turning insert provides efficient cutting performance with a neutral cutting direction.

Product Information

Standard Information

• Brand: Seco
• MPN: SECOT-34042

Technical Specifications

• ANSI Code: LCGN1603-A60 CP500
• ISO Code: LCGN1603-A60 CP500
• Chipbreaker: A60
• Corner Radius: 0.08 mm
• Finish: PVD-TiAlN+TiN Coated
• Included Angle: 60 degrees
• Length: 16.6 mm
• Thickness: 4.5 mm
• Type: Single End
• Insert Style: LCGN
• Material Grade: M
• Insert Size: 1603
• Shape: Rectangle
• Seat Size: 16
• Cutting Direction: Neutral
• For Use On: Stainless Steel
