Seco SECOT-30159 MDT Double End Turning Insert, ANSI Code: LCMF1606M0-0600-MP CP200

Product Description

The Seco SECOT-30159 MDT Double End Turning Insert is designed for precision turning tasks. This insert features a rectangle shape and is particularly effective for use on stainless steel, super alloys, and titanium materials.

• ANSI Code: LCMF1606M0-0600-MP CP200
• Neutral cutting direction with a relief angle of seven degrees
• Carbide material with PVD-TiAlN+TiN coating

Product Highlights

Ideal for medium profiling and turning tasks ensuring good accessibility.

Product Information

Standard Information

• Brand: Seco Tools
• MPN: SECOT-30159

Technical Specifications

• ANSI Code: LCMF1606M0-0600-MP CP200
• Chipbreaker: MP
• Corner Radius: 3 mm
• Finish: PVD-TiAlN+TiN Coated
• ISO Code: LCMF1606M0-0600-MP CP200
• Length: 17.9 mm
• Relief Angle: 7 deg
• Series: MDT
• Thickness: 4.12 mm
• Type: Double End
• Width: 6 mm
• Insert Style: LCMF
• Material Grade: M, S
• Insert Size: 1606
• Shape: Rectangle
• Seat Size: 16
• Cutting Direction: Neutral
• For Use On: Stainless Steel, Super Alloys and Titanium
• Material: Carbide
