Seco Larm SK-910RD2 Enforcer 2-Channel RF Receiver 10-24 VAC/VDC (2-Channel)

Brand: SECO LARM
SKU: SK-910RD2
Availability: In Stock

Ships same day if ordered by 12 pm
$63.22
$63.22
HAVE A QUESTION?

Our team is ready to help!

215-326-9845
  • Voomi Supply

    Secure Payments

  • Voomi Supply

    Easy Returns

  • Voomi Supply

    Expert Advice

  • Voomi Supply

    Fast Shipping

Description

Product Description

The SECO LARM SK-910RD2 is an Enforcer 2-Channel RF Receiver that provides independently controlled outputs to remotely operate garage doors, lights, motorized gates, and lifts. It operates on 10-24 VAC/VDC, supports 315 MHz (433.92 MHz with optional SK-93ERSD), stores up to 15 transmitter codes per channel, and offers five selectable output modes per channel. Outputs are two Form C relays rated 10 A at 14 VDC with up to 500 ft range.

  • Operates on 10-24 VAC/VDC; native 315 MHz reception, 433.92 MHz reception with optional SK-93ERSD.
  • Stores up to 15 transmitter codes per channel; pushbutton programming and five selectable output modes (timed seconds/minutes, toggle, latch, follow).
  • Two Form C relay outputs rated 10 A @ 14 VDC with NO/NC/COM screw terminal connectors; up to 500 ft range (1,000 ft with optional extended-range antenna).

Product Highlights

Dual-frequency 2-channel RF receiver with independent programming, two 10 A Form C relays, 10-24 VAC/VDC operation, and up to 500 ft range.

Product Information

Standard Information

  • Brand: SECO LARM
  • Manufacturer Part Number: SK-910RD2
Technical Specifications
Brand
SECO LARM
Manufacturer Part Number
SK-910RD2
Model
SK-910RD2
Operating Frequency
315 MHz (433.92 MHz with optional SK-93ERSD)
Input Voltage
10-24 VAC/VDC
Memory Capacity
15 transmitter codes per channel
Operating Current
Standby: 16 mA @ 12 VDC, 12 mA @ 24 VDC; Active: 60 mA @ 12 VDC, 50 mA @ 24 VDC (per channel)
Relay Output Modes
Momentary 0.05-99 sec (default 1 s), momentary 1-99 min, toggle, latch, follow (per-channel selectable)
Relay Contacts
2, Form C, 10 A @ 14 VDC
Connectors
Screw terminals with NO/NC/COM per relay and power +/-, pushbutton programming
Display
2-digit 7-segment LED
Operating Humidity
5-95% non-condensing
Operating Temperature
32 to 167 F (0 to 75 C)
Dimensions
4-3/16 x 7/8 x 2-3/8 in (107 x 23 x 60 mm)
Range
Up to 500 ft (150 m); up to 1,000 ft (300 m) with optional extended-range antenna
