Seco 17015176 Roughing End Mill 1/2 in 4 Flute Cobalt Ticn

Product Description

The SECO 17015176 is a single-end roughing end mill designed for aggressive material removal in milling applications. Built from M42 cobalt high-speed steel and coated with TiCN, this tool handles tough ferrous and non-ferrous materials where standard HSS tooling wears too quickly. It features 4 right-hand spiral flutes with a 30-degree maximum helix angle, a 1 inch length of cut, and a 3 inch overall length. The stub-length profile keeps the tool rigid under heavy chip loads. Installation is performed by qualified machinists or toolroom personnel working with vertical mills, knee mills, or CNC machining centers.

This roughing end mill suits production and job-shop environments where rapid stock removal is the priority before finishing passes. The 1/2 inch diameter and stub-length configuration make it well suited to short-reach pocketing, slotting, and profile roughing operations in steel, stainless, and similar alloys. The TiCN coating improves surface hardness and reduces built-up edge, extending tool life in interrupted cuts and abrasive materials. It is a non-centercutting design, so plunge entry is not recommended without a pre-drilled start hole.

Key Features

• M42 cobalt HSS construction for improved heat and wear resistance over standard HSS
• TiCN coating reduces friction and extends tool life in ferrous and abrasive materials
• 4 right-hand spiral flutes with 30-degree helix angle for efficient chip evacuation
• Stub-length body (1 inch LOC, 3 inch OAL) provides rigidity under heavy roughing loads
• Series REM710 roughing geometry for high material removal rates
• Non-centercutting design requires a pre-drilled entry point for plunge operations

Compatibility

Designed as a direct-fit replacement or standard tooling selection for 1/2 inch collets, end mill holders, and milling chucks accepting a 1/2 inch straight shank in vertical, horizontal, and CNC milling machines.

Installation Notes

Installation should be performed by a qualified machinist or toolroom technician. The spindle must be fully stopped and the machine locked out before changing tooling. Use a properly sized end mill holder or collet rated for 1/2 inch shank diameter and ensure the shank is seated to the recommended engagement depth per the holder manufacturer. This tool is not designed for plunge cutting; always use a ramping or pre-drilled entry strategy when accessing closed pockets.
