Seco 02815028 Turning Insert TGK1500 Solid Carbide LCMF160404

Product Description

The SECO 02815028 is a solid carbide multi-directional turning insert designed for grooving and turning operations in demanding machining environments. Running under the TGK1500 manufacturer grade with a CVD coating, this insert delivers wear resistance suited to cast iron workpieces. The LCMF160404-0400-MT catalog designation identifies the insert style as LCMF with a dog bone shape, a neutral hand orientation, and an MT chipbreaker geometry. Cutting width reaches 0.157 inches, cutting height is 0.177 inches, and corner radius measures 0.016 inches. Licensed machinists and CNC operators install this insert in MDT-series toolholders for multi-directional turning and grooving applications.

This insert is intended for use in MDT-series multi-directional turning toolholders where cast iron is the primary workpiece material, designated by material code K. The neutral hand orientation allows use on both left- and right-hand cuts depending on toolholder setup. The MT chipbreaker geometry supports controlled chip flow during grooving passes in cast iron components. Typical installations include production turning centers and CNC lathes running cast iron parts in light manufacturing or job shop environments. This insert ships individually but carries a minimum order quantity of 10 units.

Key Features

• TGK1500 grade solid carbide substrate with CVD coating for cast iron cutting performance
• Dog bone LCMF insert style with neutral hand for multi-directional grooving flexibility
• MT chipbreaker geometry for controlled chip evacuation in cast iron applications
• 0.016-inch corner radius provides edge strength during grooving passes
• MDT series designation ensures compatibility with matching MDT toolholder bodies
• Zero-degree relief angle supports stable edge engagement in grooving operations

Compatibility

Designed for use in MDT-series multi-directional turning toolholders that accept LCMF-style inserts. Primary workpiece material designation is cast iron (material code K). Refer to toolholder documentation to confirm pocket and clamping compatibility before installation.

Installation Notes

Installation of carbide turning inserts should be performed by qualified machinists or CNC tooling technicians. Power down and lock out the machine spindle before changing inserts. Use the correct torque wrench and clamping screw specified by the toolholder manufacturer — do not overtighten, as solid carbide inserts are brittle and susceptible to fracture under excessive clamping force. Inspect the insert pocket and clamping components for chips or debris before seating the new insert.
