Seco 00088699 Multi-directional Turning Insert CP600 Carbide

Product Description

The SECO 00088699 is a solid carbide multi-directional turning (MDT) insert in the LCMF160302 style, designed for high-precision grooving and turning operations. It carries the manufacturer grade CP600 with a PVD-applied TiAlN and Titanium Nitride coating for extended tool life under demanding cutting conditions. The insert features a neutral hand orientation and an MC chipbreaker geometry, making it suitable for a range of chip control requirements. Material grade C5 positions it for use across multiple workpiece material categories. This insert is installed by CNC machinists and tool-room technicians working with precision turning centers and grooving toolholders.

The 00088699 insert is used in metal-cutting applications involving materials classified under workpiece codes M, N, P, and S, covering stainless steels, non-ferrous metals, carbon and alloy steels, and heat-resistant superalloys. The double-end design provides two usable cutting edges per insert, improving cost-per-edge efficiency in production environments. It is suited to both light finishing and moderate material removal in grooving, parting, and multi-directional turning setups where tool rigidity and chip control are critical.

Key Features

• CP600 grade solid carbide with PVD TiAlN and Titanium Nitride coating for wear resistance
• Double-end insert — two cutting edges per insert for improved cost-per-edge value
• MC chipbreaker geometry for effective chip control across multiple workpiece materials
• Neutral hand orientation for flexible toolholder compatibility
• Relief angle of 7 degrees reduces cutting forces and supports edge stability
• Compatible with workpiece material codes M, N, P, and S

Compatibility

Designed for use in MDT-series LCMF-style toolholders accepting 160302-format inserts. Verify toolholder seat geometry and insert pocket dimensions before installation. No additional specific compatible model numbers were provided in the product data.

Installation Notes

Insert installation and indexing should be performed by qualified CNC machinists or toolroom personnel with the machine powered down and spindle locked. Use the appropriate torque wrench and insert clamp screw specified by the toolholder manufacturer — do not overtighten, as solid carbide inserts are brittle and may crack under excessive clamping force. Inspect the insert pocket and seating surface for chips or debris before seating the insert. Follow the cutting data recommendations provided by SECO for feeds, speeds, and depth of cut appropriate to the workpiece material and machine rigidity.
