Seco 00072753 Turning Insert CP500 Solid Carbide Mdt

Product Description

The SECO 00072753 is a solid carbide multi-directional turning insert in the MDT series, designed for precision grooving and turning operations on CNC lathes and turning centers. Built to LCMF160304-0300-MG style, this insert features a TiAlN/TiN coating applied via PVD process, which delivers consistent edge hardness and wear resistance at elevated cutting temperatures. Key cutting geometry includes a 0.118-inch maximum cutting width, a 0.177-inch cutting height, and a 0.016-inch corner radius. The micrograin carbide substrate and MG chipbreaker work together to produce controlled chip evacuation across a wide range of workpiece materials. Licensed machinists and CNC operators install and index this insert as part of standard tooling maintenance.

This insert is suited for use across a broad spectrum of workpiece material groups, including hardened steels (H), cast iron (K), stainless steel (M), nonferrous materials (N), carbon and alloy steels (P), and heat-resistant superalloys (S). Its neutral hand orientation and double-end design allow use in both left- and right-hand toolholders compatible with the LCMF insert style, making it a versatile option for shops running varied materials and programming setups. The MDT series is engineered for multi-directional cutting paths including axial and radial feed directions in a single insert.

Key Features

• Solid carbide micrograin substrate for extended tool life in demanding applications
• TiAlN/TiN PVD coating for heat resistance and reduced flank wear
• MG chipbreaker geometry promotes controlled chip formation across ISO material groups H, K, M, N, P, and S
• Double-end design maximizes insert utilization before replacement
• Neutral hand orientation fits both left- and right-hand LCMF-compatible toolholders
• 0.016-inch corner radius suitable for fine-to-medium finishing passes

Compatibility

Designed for use in toolholders accepting the LCMF insert style. Confirm toolholder bore and clamp specifications against the LCMF160304 insert size code prior to installation.

Installation Notes

Insert indexing and replacement should be performed with the machine in a full stop condition with spindle power isolated per shop lockout/tagout procedures. Use a torque wrench calibrated to the toolholder manufacturer's specified clamp screw value to avoid seat damage or insert fracture. Inspect the insert pocket seating surface for chips or debris before seating the new insert. Handle solid carbide inserts carefully to prevent chipping of cutting edges prior to use.
