Seco 00034046 Threading Insert CP500 Carbide 55 Degree

Product Description

The SECO 00034046 is a carbide threading insert designed for precision thread-cutting operations on both internal and external threads. Using the LCGN1603-G55 geometry, it covers an external pitch range of 1.75 to 3.00 mm and a TPI range of 14 to 8, making it suitable for a wide range of threading applications in production and job-shop environments. The insert carries SECO manufacturer grade CP500, a PVD-coated micrograin carbide grade known for wear resistance on steel and stainless materials. With a 55-degree included angle and neutral hand orientation, this insert fits standard MDT series toolholders. Installation is performed by machinists and tooling technicians on CNC lathes and threading machines.

This insert is used in metalworking applications where consistent thread form and tool life are critical. The MDT series designation places it within SECO tooling systems designed for multi-directional threading passes. The FG chipbreaker geometry supports controlled chip evacuation during internal and external threading cycles. It is suited for both light production runs and higher-volume threading operations across a range of workpiece materials. Each package contains one insert, with a minimum order quantity of 10 units.

Key Features

• PVD-coated CP500 micrograin carbide grade for extended tool life
• 55-degree included angle covers common unified and metric thread forms
• Pitch range of 1.75 to 3.00 mm (14 to 8 TPI) in a single insert
• Neutral hand orientation for flexible toolholder pairing
• FG chipbreaker for controlled chip flow on internal and external cuts
• Compatible with both internal and external threading operations

Compatibility

Designed for use in SECO MDT series threading toolholders accepting LCGN 1603 style inserts with a 55-degree included angle.

Installation Notes

Threading inserts should be seated and torqued per the toolholder manufacturer specifications using the correct torx or hex key. Ensure the machine spindle is fully stopped and all motion is locked out before changing inserts. Inspect the insert pocket and seating surface for chips or debris prior to installation. Verify thread pitch and TPI settings on the CNC program before the first threading pass.
