Seco 00029208 Tapered End Mill Solid Carbide 3 Flute

Product Description

The SECO 00029208 is a solid carbide tapered end mill from the HK series, designed for precision milling operations requiring a controlled taper angle. With a 30-degree taper angle per side and a small end diameter of 0.0984 inches (2.50 mm), this tool is built for tight-tolerance work in die, mold, and contour milling applications. The square end geometry and three-flute spiral configuration deliver clean material removal with good chip evacuation. This end mill is uncoated (bright finish) and is installed and operated by machinists and CNC tooling professionals in production and job-shop environments.

This tool suits milling operations on cast iron, steel, non-ferrous metals, and superalloys, as identified by primary workpiece material codes K, M, N, P, and S. The 0.3937-inch (10.00 mm) length of cut and 10.00 mm shank diameter make it appropriate for moderate-depth tapered cavity work in both vertical and horizontal machining centers. Right-hand flute direction is standard for conventional CNC spindle rotation. It is not center-cutting and does not support coolant-through delivery.

Key Features

• 30-degree taper angle per side for precise angled wall and cavity profiles
• Solid carbide construction for rigidity and wear resistance in ferrous and non-ferrous materials
• Three-flute spiral geometry balances chip clearance with cutting surface contact
• Square end profile for flat-bottom tapered features
• Uncoated bright finish suitable for a broad range of workpiece materials
• Shank diameter tolerance h5 for consistent tool holding fit

Compatibility

Designed as an OEM-style replacement or direct-use tapered end mill compatible with standard tool holders accepting a 10.00 mm shank diameter with h5 tolerance; verify machine spindle compatibility and collet size before installation.

Installation Notes

Installation and setup should be performed by a qualified machinist or CNC tooling technician. Power down and lock out the machine before seating or removing the tool from the holder. Confirm runout does not exceed the rated TIR maximum of 0.0008 inches after clamping. Do not use this end mill for plunge cutting, as it is not center-cutting.
