Schunk 1323568 Cnc Quick-change Clamping Module Nsl

Product Description

The SCHUNK 1323568 is a manual CNC quick-change clamping module in the NSL series, designed for precision workholding in machining centers and automated production cells. It provides a retention force of 7,500 kN and requires an unlocking pressure of 87 psi (6 bar) to release the clamping action. The module features a top-mount configuration with a single module center and delivers a repeatability of 0.0050 mm (0.000200 inches), making it suitable for applications where consistent part positioning is critical. Licensed machinists and CNC setup technicians are the primary installers of this component.

This clamping module is intended for use in CNC machining environments where rapid workpiece changeover is required without sacrificing positional accuracy. The top-mount design integrates into pallet or fixture systems that require a reliable manual quick-change interface. With a single module center, it is well suited for compact fixture layouts and dedicated part-holding applications in both job-shop and production settings where repeatable locating is a priority.

Key Features

• Manual actuation for direct operator control without pneumatic or hydraulic supply at the clamping stage
• Retention force of 7,500 kN for robust workpiece security during heavy machining operations
• Unlocking pressure of 87 psi (6 bar) for controlled, repeatable release
• Repeatability of 0.0050 mm (0.000200 inches) supports tight-tolerance part changeover
• Top-mount hole location simplifies integration into existing fixture plates and pallet systems
• NSL series design provides a standardized quick-change interface across compatible tooling setups

Compatibility

Designed as an OEM-style replacement or direct integration component for CNC quick-change clamping systems utilizing the NSL series top-mount manual interface with a single module center configuration.

Installation Notes

Installation should be performed by a qualified machinist or tooling engineer familiar with CNC workholding systems. All machine power and any hydraulic or pneumatic supplies to the fixture should be isolated before mounting or dismounting the clamping module. Mounting surfaces must be clean and free of chips or burrs to maintain the specified repeatability. Fastener torque values and locating surface requirements should be referenced from the SCHUNK NSL series installation documentation provided with the unit.
