Schneider Electric ZB6AA2 Push-button Switch 16mm Momentary

Product Description

The SCHNEIDER ELECTRIC ZB6AA2 is a 16 mm non-illuminated momentary push-button switch operator designed for industrial control panel applications. The flush-mounted, round black plastic pushbutton provides a momentary contact action, returning to its default position immediately upon release. Rated for NEMA 4, 4X, and 13 enclosures, this operator is built for vibration-resistant service in demanding environments. It is a compact unit measuring 1.2 inches in length and 0.6 inches in both height and width, weighing 0.01 pounds. Licensed electricians and control panel builders are the primary installers for this type of component.

The ZB6AA2 is suited for use in industrial machinery, control stations, and automation panels where a reliable momentary switching action is required. The 16 mm mounting hole diameter fits standard 16 mm cutout panel openings common in commercial and industrial electrical enclosures. Its NEMA 4X rating makes it appropriate for wash-down and corrosive-environment installations. The non-illuminated design keeps panel wiring simple in applications where indicator lighting is not required.

Key Features

• 16 mm mounting hole diameter fits standard industrial panel cutouts
• Momentary (MO) operation — returns to default position on release
• Non-illuminated flush round black plastic operator
• Vibration-resistant construction for demanding service environments
• NEMA 4, 4X, and 13 enclosure ratings including wash-down and corrosion-resistant applications
• Certified to UL 508, CSA C22.2 No. 14, EN/IEC 60947-5-1, and multiple international standards

Compatibility

Designed as an OEM-style replacement or new-installation operator for 16 mm push-button switch assemblies used in industrial control panels and automation equipment.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and applicable local codes. De-energize the panel and verify zero voltage before beginning any work on control circuits. The operator mounts through a 16 mm panel cutout and secures with the appropriate contact block and retaining collar. Do not exceed the enclosure rating by installing in environments more severe than the NEMA 4X designation allows.
